Kobelco SK 200
Prijs excl. BTW
54
5
Favoriet
Delen
Zoekopdrachten bewarenAfdrukken
INFORMATIE
Productgroep
Rupsgraafmachines
Merk / model
Kobelco SK 200
Bouwjaar
2025
Aantal gebruiksuren
1.000 h
Status
Hersteld / Reconditioned,Gereviseerd / Remanufactured
Land
China
Algemene score
1
2
3
4
5
Mascus ID
8A50C8DA
PRIJZEN
Valuta kiezen
DETAILS
Voorraad nummer
QFSG001
Type
Diesel
Motor
6D34-TLU2D
Totaalgewicht GVW
20.000 kg
Motor vermogen
110 kW (150 pk)
Motorfabrikant
Mitsubishi
Inhoud graafbak
0,80 m3
Rupsbreedte
600 mm
Vermogen aanvullende hydraulica
340 l/min
Topsnelheid
55 km/h
Originele kleur
blue
Land van productie
China
Leveringsvoorwaarden
FOB, CIF
Certificaten
EPA, CE, TÜV
Overige informatie
Specification
powerTraditional power
ManufacturerJoint venture/import
bucketbackhoe
Tonnage (tons)20
Machine operating weight (kg)20000
Bucket capacity (m³)0.8
performance
Rotation speed (rpm)11
Walking speed (km/h)1st speed: 4.0 2nd speed: 6.0
Gradeability (%)70
Ground pressure (Kpa)45；35
Bucket digging force (kN)143; Boost state: 157
Arm digging force (kN)97.1; boost state: 107
Powertrain
Engine modelMitsubishi 6D34-TLU2D
Rated power (kw/rpm)110/2000
Cooling methodWater cooling
Working formWater-cooled, four-stroke, six-cylinder, direct injection, turbocharged, built-in intercooler
hydraulic system
Main pump typeDuplex variable displacement axial piston pump pilot gear pump
Main overflow setting pressure (Mpa)34.3; Boost: 37.8
Oil capacity
Fuel tank (L)340
Main body size
Track shoe width (mm)600；800
Achieve Innovations
5F Building 4, No.28, (M) Fuyuan Road, Kaifu Dist 410003 Changsha Hunan 湖南 China
