CAT 330 GC

We're from Shanghai Jipan Trade Co.,Ltd.I'm the Sales Manager, specializing in selling used machines from various brands, including excavators,truck cranes,crawler cranes,and so on.With extensive export experience, our machines are sold well in Europe, America, Africa,and other regions, receiving rave reviews and a high repurchase rate. We uphold the principles of integrity and quality, and have a professional service team to provide you with one-stop service, ensuring accurate, efficient, and safe delivery of your machines.We are committed to building long-term relationships with every customer from around the world with competitive prices and superior quality. Contact: Jason WhatsApp/Mobile:0086 13675656717 WeChat:+86 13675656717 Shipping Method:Container Vessel, Bulk Carrier, Flatbed Vessel, or RoRo Vessel. If you don't have your own shipping agent, we can ship on your behalf and offer you the lowest possible shipping rates.

Parameter configuration of CAT330 GC hydraulic excavator Specification Tonnage (tons)30 The overall working weight of the machine (kg) is 30,400 Bucket capacity (m³)1.6 Boom length (mm)6.15 The length of the boom (mm) is 3.2 Performance Rotational speed (rpm):11.5 The rotary torque (Nm) is 105k Bucket digging force (kN)179 The digging force of the bucket arm (kN) is 126 Power system Engine model Cat C7.1 Rated power (kw/rpm)151/2200 Displacement (L)7.01 Cylinder diameter × stroke (mm):105*135 Hydraulic system The maximum flow rate of the main pump (l/min) is 560 Working hydraulic circuit (Mpa)35 Walking hydraulic circuit (Mpa)35 Rotary hydraulic circuit (Mpa)28.4 Oil capacity Fuel tank (L)474 Hydraulic oil tank (L)147 Hydraulic System (L)310 Engine oil change volume (L):25 Coolant (L)25 Main body size Total transportation length (mm):10420 The total transportation width (mm) is 3190 The total transportation height (mm) is 3050 The total length of the tracks (mm) is 4850 Track plate width (mm)600/800 Track gauge (mm):2590 The ground clearance of counterweights (mm) is 1110 Minimum ground clearance (mm):490 The center distance of the idler wheels (mm) is 3990 Rear end turning radius (mm):3130 Scope of work Maximum excavation radius (mm):10,690 Maximum excavation depth (mm):7260 Maximum excavation height (mm):9980 Maximum unloading height (mm):6930 Maximum vertical excavation depth (mm):6030
