INFORMATIE

Productgroep
Minigraafmachines < 7t
Merk / model
Doosan DH 55
Bouwjaar
2024
Aantal gebruiksuren
470 h
Land
China
Algemene score
1
2
3
4
5
Mascus ID
93029710

PRIJZEN

Valuta kiezen

DETAILS

Voorraad nummer
1
Serienummer
1
Type
Diesel
Laatste inspectie
2025-07-08
Aantal vorige eigenaren
1
Staat van het onderstel
Good Condition
Totaalgewicht GVW
5.250 kg
Kentekennummer
1
Vermogen aanvullende hydraulica
55 l/min
Emissieklasse
Fase V
Rupsbreedte
400 mm
Inhoud graafbak
0,75 m3
Afmetingen (LxBxH)
5940 x 2420 x 2546 mm
Originele kleur
Original
Motor
Original
Motor vermogen
40,5 kW (55,1 pk)
Motorfabrikant
Original
Voorwaarden info/Garantie
1 Year
Land van productie
Zuid-Korea
Leveringsvoorwaarden
FCA, FOB, CIF, EXW
Certificaten
EPA, CE
Toebehoren
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.
Accessoires
Kabelkast
Airconditioning
Aanvullende hydraulica
Motor voorfilter
Laat meer zien
Overige informatie
Parameter configuration of Doosan DH55 excavator Specification The working weight of the entire machine (kg) is 5250 Bucket capacity (m³) : 0.13-0.175 Tonnage (tons)5 Bucket backhoe Power Traditional Power Bucket backhoe Joint venture with manufacturers & import Power Traditional Power Performance Rotational speed (rpm) : 0-9.0 Walking speed (km/h)3.8/2.1 Climbing ability (%) : 30 Bucket digging force (kN)3.71 The digging force of the bucket arm (kN) is 2.66 The maximum traction force (kN) is 4800 Power system The engine model is original Isuzu 4JG1 Rated power (kw/rpm) : 134940.5 Displacement (L)2.771 Number of cylinders (4) Hydraulic system Main pump type: Kawasaki The maximum flow rate of the main pump (l/min) is 2-55 Walking hydraulic circuit (Mpa)210 Rotary hydraulic circuit (Mpa)220 Oil capacity Fuel tank (L)115 Hydraulic oil tank (L)80 Engine oil change volume (L) : 9.7 Coolant (L)10 Main body size The total transportation length (mm) is 5940 The total transportation width (mm) is 2420 The total length of the track (mm) is 2546 The total width of the track (mm) is 1880 Track gauge (mm) : 1408 Minimum ground clearance (mm) : 350 Scope of work Maximum excavation radius (mm) : 6100 Maximum excavation depth (mm) : 3890 Maximum excavation height (mm) : 5330 Maximum vertical excavation depth (mm) : 3025

上海吉潘贸易有限公司

上海市松江区车墩镇莘莘路32号3799 201600 上海 上海 China
