CAT 313

Name: CAT 313
Brand: CAT
SKU: 007372FA
Price: 16820 USD
Availability: InStock

Prijs excl. BTW

Favoriet

Zoekopdrachten bewaren

Afdrukken

INFORMATIE

Productgroep

Midigraafmachines 7t - 12t

Merk / model

CAT 313

Bouwjaar

2022

Aantal gebruiksuren

700 h

Land

China

Algemene score

Mascus ID

007372FA

PRIJZEN

Valuta kiezen

DETAILS

Aantal vorige eigenaren

Staat van het onderstel

good

Totaalgewicht GVW

13.000 kg

Emissieklasse

Stage V / Tier IV Final

Motor vermogen

90 kW (122 pk)

Motorfabrikant

japan

Inhoud graafbak

0,65 m³

Rupsbreedte

600 mm

Afmetingen (LxBxH)

761024902.83 m

Originele kleur

YELLOW

Lengte lepelsteel

960 mm

Voorwaarden info/Garantie

good

Land van productie

Japan

Leveringsvoorwaarden

FOB, EXW

Certificaten

EPA, CE, ANSI, AS, CSA, EAC GOST, TRUA, JIS, TÜV, ASME

Toebehoren

All the auxiliary accessories can be provided for you. The above information is for reference only, and the specific details need to be confirmed with the factory.

Accessoires

Hydraulische snelwissel

Slangbreukbeveiliging hefcilinder

Slangbreukbeveiliging knikcilinder

GPS-systeem

Laat meer zien

Overige informatie

Here are the parameters of Caterpillar CAT313 excavator: - **General Parameters** - **Model**: CAT®313 GC - **Working Weight**: 12,400 kg - **Bucket Capacity**: 0.53 m³ (0.6 m³ is optional) - **Engine Parameters** - **Engine Model**: Cat C3.6 - **Rated Power - ISO 14396**: 74.4 kW - **Rated Power - ISO 9249**: 70.6 kW - **Rated Speed**: 2200 r/min - **Displacement**: 3.6 L - **Bore × Stroke**: 98 mm × 120 mm - **Emission Standard**: National IV - **Hydraulic System Parameters** - **Main System - Maximum Flow - Equipment**: 247 L/min - **Maximum Pressure - Equipment - Normal**: 35,000 kPa - **Maximum Pressure - Travel**: 35,000 kPa - **Maximum Pressure - Swing**: 26,000 kPa - **Swing System Parameters** - **Swing Speed**: 11.5 rpm - **Maximum Swing Torque**: 43 kN·m - **Dimensions and Working Ranges** - **Boom Reach**: 4.65 m - **Stick Reach**: 2.5 m - **Shipping Height**: 2780 mm (top of cab) - **Handrail Height**: 2820 mm - **Shipping Length**: 7630 mm - **Tail Swing Radius**: 2160 mm - **Counterweight Clearance**: 895 mm - **Ground Clearance**: 425 mm - **Track Length**: 3490 mm - **Distance between Center of Track Rollers**: 2780 mm - **Track Gauge**: 1990 mm - **Transport Width**: 2490 mm - **Maximum Digging Depth**: 5770 mm - **Maximum Reach at Ground Level**: 8210 mm - **Maximum Cutting Height**: 8530 mm - **Maximum Loading Height**: 6070 mm - **Minimum Loading Height**: 1980 mm - **Maximum Depth Cut for 2440 mm Level Bottom**: 5370 mm - **Maximum Vertical Wall Digging Depth**: 5040 mm - **Force Parameters** - **Bucket Digging Force - ISO**: 95.7 kN - **Stick Digging Force - ISO**: 68.2 kN - **Oil Capacity** - **Fuel Tank**: 237 L - **Hydraulic Tank**: 77 L - **Cooling System**: 11 L - **Engine Oil**: 11 L - **Final Drive**: 3 L per sideLaat meer zien
