Fontaine 60LCC

Description: Length 52'3" Width 102" Main Deck Length 26' Main Deck Height 18" Weight 24,051 lbs. Unit Description Magnitude 60LCC Flat Body Compatibility Designed to Accept 35" Neck Extention & Flip Axle Floor 2" Nominal Wood - Side Rails Only Ramps Manual Front approach ramps Outriggers 13 pair - Removable Swing Type / 2 pair removable D-Rings 19 pair Toolbox 2 Trays - fully Covered between main beams Side Rail Lights (3) Marker LIghts per Side incl. Mid-Turn Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Battery Powered Rear Amber Strobes Flag Holders 1 Pair Modular Connection Fixed Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel Dual Cam Pawl Arm w 7 Ride Height Positions, 50" Pony Motors None Suspension # of Axles 3 Suspension Type Air Ride Suspension Setting 54.5" Lift Axle Rear Axle Air Lift Flip Axle Not Included Manual Dumpvalve Yes Raise & Lower Valve Mechanical Ride Height Control Valve Tire Size 275/70R22.5 Wheels (6) Polished Alum (6) Steel Disc Liquid Filled Gauge Yes UnderFrame King Pin Setting 16" Cross Member Center 24" Centers Paint Black Weight Ratings 60 Ton in 13' Length w/ Closed 4-Axle Compatibility with Spreader Bar and/or 35" Flip Box 7 Variable ride Height Positions 102" Swing Radius Removable Kingpin at 102" Radius Low Boom Well Chain Lift Axle on Front Axle Length: 636.000000000000 Width: 102 Quantity: 1 Suspension: Air Ride Wheels: Aluminum/Steel Axle: Tri Composition: Steel Outriggers: 1
