Jekko SPX328CL
Prijs excl. BTW
Prijs op aanvraag
Afdrukken
INFORMATIE
Productgroep
Minikranen
Merk / model
Jekko SPX328CL
Bouwjaar
2025
Status
Demo
Land
Polen
Algemene score
1
2
3
4
5
Mascus ID
5FDC685A
DETAILS
Aantal vorige eigenaren
1
Totaalgewicht GVW
2.300 kg
Maximale hefcapaciteit
2.800 ton
Afmetingen (LxBxH)
2950 x 730 x 1610 mm
Voorwaarden info/Garantie
TAK
Resterend profiel voorbanden
100
Resterend profiel achterbanden
100
Leveringsvoorwaarden
EXW
Certificaten
CE
Toebehoren
Orbital motor winch 700 kg, 60m rope, 7 mm for SPX328 + 1T single line hook
2,8 ton - 3 sheave pulley block D7 rope
Rest position frame for Pulley Block Hook
300x300mm Outrigger Mats for SPX328 on outriggers
Mechanical Luffing Jib, 600 kg SWL, 1 manual extension
Accessoires
Hijshaken
Overige informatie
Lithium Battery powered mini crane mod. SPX328CL
N°1 Lithium Battery 48V-3F 10 kW/h - 210Ah
HF Battery Charger 50-60Hz, 220V-50A
Nr 4 hydraulic telescopic sections
HMI 10" touch screen IP66
360° continuous rotation on slewing ring
Variable Displacement Piston Pump
Radio Remote Control (RCD)
Load And Moment Indicator (LMI)
Geometrical Stability Control (GSC)
Crane Carrier Interlock (CCI)
Anti To Block (A2B)
Diagnostic Trouble Code (DTC)
Plug & Play Attachments (PPA)
Crane Multi Speed (CMS)
JTP connector
LED working light
Tower lamp
USB stick with Manuals & Documents
Color: Orange RAL2004, Grey RAL7021
